zn48
share：
selection guide
|
product name |
input mode |
sequence |
type |
|
zn48 explosion-proof zn48 |
c：dc l：ac |
a：ammeter v：voltmeter |
main features
■show the trend of change, the reading is convenient
main technical parameters
|
item |
technical data |
|
national standard |
gb/t 7676.1~9 |
|
accuracy class |
1.5 class、2.5 class |
|
puncture test |
frequency50hz、voltage2000v、duration1min |
|
environment condition |
temperature：-20～ 40℃，relative humidity ≤85%（25℃）；damping ≤4s |
|
resistance to mechanical properties |
can withstand the acceleration of 30m/s2 and impact frequency per minute 80～120 times 2 hours of transport shock |
|
operating position |
vertical |
|
outline dimension |
outline dimension：48mm×48mm portiforium dimension：44mm×44mm |
48c-a、v wiring diagram
48l-a、vwiring diagram
