85l17
share：
selection guide
|
product name |
input mode |
sequence |
type |
|
85 |
c：dc l：ac |
17 |
a：ammeter v：voltmeter w：active power meter var:reactive power meter hz：frequency table cos:power factor meter |
|
input mode |
type |
|
dc |
ammeter、voltmeter |
|
ac |
ammeter、voltmeter、active power meter、reactive power meter、frequency table、power factor meter |
main features
■show the trend of change, the reading is convenient
■transparent organic glass
■the card using the surface frame installation
main technical parameters
|
item |
technical data |
|
national standard |
gb/t 7676.1~9 |
|
accuracy class |
2.5 class |
|
puncture test |
frequency50hz、voltage2000v、duration1min |
|
environment condition |
temperature：-20～ 40℃，relative humidity ≤85%（25℃）；damping≤4s |
|
resistance to mechanical properties |
can withstand the acceleration of 30m/s2 and impact frequency per minute 80～120 times 2 hours of transport shock |
|
operating position |
vertical |
|
outline dimension |
70mm×40mm×64mm |
85c17-a、vwiring diagram
85l17-a、vwiring diagram
85l17-hzwiring diagram
85l17-w、varwiring diagram
85l17-cosφwiring diagram
