42l6
share：
selection guide
|
n |
input mode |
sequence |
type |
|
42 |
l：ac |
6 |
a：ammeter v：voltmeter w：active power meter var:reactive power meter hz：frequency table cos:power factor meter |
main features
■show the trend of change, the reading is convenient
■bolt fastening installation
main technical parameters
|
item |
technical data |
|
national standard |
gb/t 7676.1~9 |
|
accuracy class |
1.5 class、2.5 class |
|
puncture test |
frequency50hz、voltage2000v、duration1min |
|
environment condition |
temperature：-20～ 40℃，relative humidity≤85%（25℃）；damping≤4s |
|
resistance to mechanical properties |
can withstand acceleration of 30m/s2 a and impact frequency per minute 80～120 times 2 hours of transport shock |
|
operating position |
vertical |
|
outline overall and installing dimensions |
outline dimension：120 mm×120 mm installation dimensions：112 mm×112 mm |
42l6-a、vwiring diagram
42l6-hzwiring diagram
42l6-w、varwiring diagram
42l6-cosφwiring diagram
